Yuav tsum muaj hluav taws xob zoo li qub rau chav huv
(1) Chav huv
Semiconductors, tiaj-vaj huam sib luag kua siv lead ua zaub, optoelectronics, thiab biomedicine txhua qhov xav tau kev cob qhia tsim khoom huv. Feem ntau, cov chav huv huv hais txog chav lossis qhov chaw txwv nyob qhov twg cov huab cua nyob hauv qhov chaw raug tswj nyob hauv qhov txwv txwv. Qhov tsawg dua qhov tsawg ntawm cov hais, qhov siab dua qhov huv.
(2) Hluav taws xob zoo li qub hauv chav huv
Vim yog qhov yuav tsum tau ua kom huv ntawm chav huv, siv sab hauv tsev
① Muaj ntau cov khoom siv dai kom zoo nkauj uas muaj qhov nruab nrab rwb thaiv tsev zoo, hauv plag tsev, phab ntsa, qhov rooj, qab nthab, ntu, rooj ua haujlwm, rooj zaum, thiab lwm yam.
Yas pem teb 500V ~ 1000V hauv chav thaij duab, 500V ~ 1500V hauv chav diffusion, 500V ~ 1500V hauv pobzeb pem teb, 700V rau cov ntawv yas, OV ~ 1000V rau yas qab nthab, 500V ~ 3000V rau hlau txav rooj zaum tawv tawv.
Hen Thaum tib neeg hnav khaub ncaws huv, khau, taug kev lossis ua haujlwm, sib txhuam nrog cov khoom sib txawv, cov cuab yeej siv thiab khoom siv yuav tsim hluav taws xob zoo li qub, thiab tib neeg, khaub ncaws, thiab khau yuav raug them.
Cov tib neeg hnav cov khaub ncaws nylon thiab cov khau yas ua los ntawm cov khau taug kev maj mam rau hauv pem teb huv, nrog 7000V ~ 8000V qhov hluav taws xob zoo li qub ntawm lawv lub cev.
1200V (10%~ 20%RH), 250V (65%~ 90%RH) tuaj yeem siv rau kev taug kev ntawm cov yas yas, 35000V (10%~ 20%RH), 1500V (65%~ 90) tuaj yeem siv rau kev taug kev ntawm cov ntaub pua plag %RH), cov kab sib dhos ua ke, cov khaub ncaws ua haujlwm uas tib neeg hnav tuaj yeem ncav cuag 10KV.
③ Cov cua txias ntawm lub tshuab cua txias dhau los ntawm cov lim dej ua ntej, lim cov txiaj ntsig nruab nrab, thiab lub lim dej ua haujlwm tau zoo, thiab lub tshuab lim dej kom huv yog raug them hluav taws xob.
Aluminium phaj huab cua muab thiab xa cov pa tawm yog 500 ~ 1000V.
④ Cov cuab yeej siv hluav taws xob ntau, cov cuab yeej thiab cov cuab yeej tseem yog qhov tseem ceeb ntawm kev siv hluav taws xob. Wafer los ua ke kab ntau lawm: wafer loading lub thawv 35KV, plexiglass npog 8KV, quartz khoom 1.5KV, wafer tais 6KV, acrylic npog 20KV, cov lus saum 10KV, yas yas txee 30KV, iav iav siv lead ua lub thawv ntim swb hla lub rooj polypropylene saum nrog 10KV.
Nyob rau hauv luv luv: qhov ntau dua qhov xav tau ntawm chav huv, qhov hnyav dua qhov kev siv hluav taws xob.
